Homogenizers
Homogenizer/Mixer/Emulsifier: 200L
R 199,700.00
High Shear Homogenizer/Mixer/Emulsifier: 200L
Catalogue price shown. Availability, delivery and the final total are confirmed by quotation. Online payments are not yet enabled.
Description & specifications
High Shear Homogenizer/Mixer/Emulsifier: 200L
Mixing tanks come in various sizes and can be used in a wide range of industries. We are a manufacturer of stainless steel mixing tanks designed to fit your products and processes.
Description:
This series is the most advanced blending equipment in fields of Chemical, pharmaceutical, food, etc. When the high-speed super-fine emulsification paddle works, it throws the materials in the center of rotor to stator at a high speed, then through tooth clearance of stator ,and shearing, collision and crushing between rotor and stator, the super-fine emulsification is realized. therefore, it is an integrated equipment comprising functions such as blending, emulsifying, homogenizing, solving and crushing.
Essential details
Mixer Type: Homogenizer
Barrel Volume (L): 1000
Material Processed: Chemicals, Food, Medicine, Powder
Max. Loading Volume (L): 200 L
Range of Spindle Speed(r.p.m): 1 – 3000 r.p.m
Max. Loading Capacity: 200L
Weight (KG): 400 KG
Material: SUS304, SUS304L, SUS316, SUS316L, Ti
Condition: New
Product Type: Liquid, juice, shampoo, chemical
Application: Liquid/Food/Medicine/Chemicals/powder
Additional Capabilities: Mixer
Brand Name: ACE
Voltage: Customized
Dimension(L*W*H): Customized
Power (kW): 6.5 kW
Warranty: 3 years
Key Selling Points: Automatic
Applicable Industries: Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Home Use, Retail, Food Shop, Printing Shops, Construction works , Food & Beverage Shops
Marketing Type: New Product 2020
Machinery Test Report: Provided
Video outgoing-inspection: Provided
Warranty of core components: 1.5 years
Core Components: Motor, Pressure vessel, Pump, PLC
Stirring Method: Anchor type mixing stirrer and homogenizer
Mixing speed of stirrer: 10-65r.p.m
Mixing speed of homogenizer: 100-3000r.p.m
Internal surface Treatment: Polishing
Heating method: Electric or steam
Tags: high shear/stainless steel/high speed
Stirrer type: Anchor type, paddle type, frame type
Be suitable for: Fluid, fruit juice, milk tea, shampoo, liquid soap etc.
Speed control: Stepless speed variation device,adjustable
Keywords: Vacuum Homogenizing Equipment Mixer Tank
